Effluent Pump Models 151, 152, 153
- Durable, cast iron construction
- Model 151 (60 Hz) comes standard with a glass-filled, polypropylene base
- Corrosion-resistant, powder coated epoxy finish
- Stainless steel lifting handle
- Assembled with stainless steel bolts
- Non-clogging, engineered thermoplastic, vortex impeller design
- Model 151 (60 Hz) - 1/3 HP, passes 1/2" (13 mm) spherical solids
- Model 152 - 4/10 HP (0.56 KW), passes 3/4" (19 mm) spherical solids
- Model 153 - 1/2 HP (0.71 KW), passes 3/4" (19 mm) spherical solids
- Motor - 3450 RPM, oil-filled, hermetically-sealed, automatic reset thermal overload protected
- Carbon/Ceramic seals
- Upper sleeve bearing and lower ball bearing running in bath of oil
- 20' (6 m), UL listed power cord with molded, 3-wire plug
- 1-1/2" NPT vertical discharge
- BN and BE standard models include a 20' (6 m), variable level float switch
- Operates at temperatures to 130° F (54° C) in effluent applications
- All models include a 1-1/2" x 2" PVC adapter fitting
- Timed dosing panels
- Electrical alternators for duplex systems are available and supplied with an alarm
- Variable level control switches are available for controlling 1 Ph systems
- Double piggyback, variable level float switches are available for variable level, long and short cycle controls
- Sealed Qwik-Box available for outdoor installations
- Over 130°F (54°C) - special quotation required
Consult Factory for Special Applications:
